Automatic Powder Filling Machine

A fully automatic powder filling machine operates without manual intervention after the initial setup. Containers (bags, cans, bottles, pouches) are automatically indexed into the fill station via conveyor, filled to the target weight, and conveyed away to closing, coding and packing stations — all under PLC control. "Fully automatic" describes the entire filling cycle: (1) automatic container in-feed and positioning; (2) automatic fill and weight control; (3) automatic container out-feed. Options like automatic bag hanging, capping, labelling and palletising extend the automation level further. Fully automatic systems are chosen when throughput exceeds what a semi-automatic machine and one operator can achieve, typically >500 kg/day.

Speed depends on fill weight, powder flowability and machine configuration. Single-head inline automatic (100g–5kg): 30–80 fills/min. Dual-head rotary (100g–5kg): 60–150 fills/min. Multi-head rotary (10–16 stations, 50g–2kg): 100–300+ fills/min. For large-weight fills (10–25kg bags), 20–60 bags/min is typical. For small sachets (<100g) on a high-speed multi-lane VFFS line with combination weigher: up to 400–600 fills/min. These rates are for a single machine — a complete line with upstream and downstream automation can sustain production at the machine's maximum rated speed.

Modern fully automatic powder filling machines are designed around recipe management and clean changeover planning. The final process depends on powder type, container format, allergen or pharma controls, and whether augers, funnels, hoppers or guide rails must be changed. Share your product list and cleaning requirement so the changeover workflow can be reviewed in the quotation.

HEMUfill fully automatic powder filling machines support industrial integration: OPC-UA server for SCADA and MES connectivity; Modbus TCP/IP and Ethernet/IP for PLC-to-PLC communication; barcode scanner or RFID reader at in-feed for product identity verification; checkweigher with SPC (Statistical Process Control) data output; vision system for container inspection (cap on/off, label placement, fill level check); serialization and traceability interface (GS1, 2D barcode); remote monitoring and diagnostics via VPN or cloud dashboard. Integration with ERP (SAP, Oracle, custom) for batch management and production reporting is available as a project option.

ROI depends on labor cost, shift pattern, target output, fill weight, container handling, cleaning time and downstream automation. Instead of using a generic payback number, send your current output, operator count, daily shifts and target capacity so the automation case can be reviewed against your real production plan.

A fully automatic inline auger filler (single head, 50g–2kg, 30–60 fills/min): scope-based quotation. Fully automatic rotary auger filler (4–8 heads, 100–200 fills/min): scope-based quotation. Complete fully automatic line with combination weigher + VFFS + checkweigher: scope-based quotation. Pharmaceutical-grade fully automatic line with GMP documentation: scope-based quotation. Prices vary based on fill weight range, powder type, speed, container format and integration level. Contact us with your specifications for a detailed proposal.
