Beverage Filling Machine

A beverage filling machine is a filling system designed specifically for liquid drink products — water, juice, carbonated soft drinks, tea, energy drinks and dairy beverages. Beverage fillers differ from general liquid fillers in three key ways: (1) they use CIP (clean-in-place) circuits to sanitise the product-contact surfaces between production runs without disassembly; (2) for carbonated beverages they use counter-pressure filling to maintain CO₂ in solution; (3) they are designed for high-speed operation (thousands to tens of thousands of bottles per hour) with continuous or high-frequency batch motion.

Counter-pressure filling is the technique used to fill carbonated beverages (soda, sparkling water, beer) without losing CO₂. The empty container is first pressurised with CO₂ to match the pressure of the carbonated product. The liquid is then filled against this back-pressure, so CO₂ stays in solution during filling. After filling, the pressure is slowly released before the cap is applied. Without counter-pressure filling, the carbonation would foam up and escape as soon as the liquid entered the container, resulting in under-fill, foaming and quality problems.

Inline beverage filler (4–8 heads): 1,000–6,000 bottles/hr. Suitable for craft beverages, pilot lines and small breweries. Rotary beverage filler (12–24 heads): 3,000–12,000 bottles/hr. Standard for medium beverage producers. Rotary beverage filler (30–60 heads): 12,000–36,000+ bottles/hr. Large-scale beverage and water bottling plants. Speed depends on fill volume, product type (still vs. carbonated), container type and head count. Share your daily production target and shift hours for a capacity recommendation.

Yes. Food-grade and beverage filling machines include CIP (clean-in-place) circuits as standard. CIP sends cleaning solution and rinse water through all product-contact surfaces — product tank, fill valves, fill nozzles and associated pipework — without disassembly. A typical CIP cycle for a beverage line: (1) Pre-rinse with water to flush product residue. (2) Caustic wash (NaOH concentration confirmed by cleaning protocol at 60–80°C) for 20–30 min. (3) Intermediate water rinse. (4) Acid rinse (HNO3 concentration confirmed by cleaning protocol) for 10–15 min. (5) Final water rinse. Total CIP cycle time: 45–90 minutes. Juice and dairy lines may add a hot-water or steam SIP (steam-in-place) step for additional sanitation.

Inline 4-head still water/juice filler (1,000–3,000 bt/hr): scope-based quotation. Rotary 12-head still water line (3,000–6,000 bt/hr, with capper): scope-based quotation. Rotary 24-head carbonated beverage filler with counter-pressure: scope-based quotation. Complete beverage line (fill + cap + label + coder + inspection): scope-based quotation. Rotary high-speed line (30,000+ bt/hr): scope-based quotation. Contact us with your beverage type, container, fill volume and production rate.
